FTI DB SERIES - DB11
Sealless Magnetic Driven Centrifugal Pump
The FTI DB SERIES - DB11 offers powerful performance with a compact, leak-free design. It utilizes magnetic drive technology to provide long-lasting, maintenance-free operation, making it perfect for processing aggressive chemicals and liquids. Engineered for safety and durability, the DB11 ensures optimum reliability in critical systems.
TECHNICAL SPECIFICATIONS:
Suction Port Size | 2 in |
|---|---|
Discharge Port Size | 1.5 in |
Connection Types | NPT, BSP, Flange, or Union |
Maximum Specific Gravity | over 1.8 |
Maximum Working Pressure | 90 psi (6.2 bar) |
Type | Sealless Mag Drive |
|---|---|
Configuration | Horizontal |
Construction Materials | Polypropylene or PVDF |
O-Ring Materials | FKM, EPDM, Simriz®, or Kalrez® |
Bushing Materials | Carbon, PTFE, Ceramic, or SiC |
Shaft Materials | Ceramic, Hastelloy® C, or SiC |
@3450 RPM | @2900 RPM | |
|---|---|---|
Flow Range* | 4 to 116 gpm | 0.9 to 26.8 m3/h |
Maximum Head | 74 ft | 23 m |
Power Range** | 0.28 to 1.74 hp | 0.37 to 1.38 kW |
*Based on 1.0 specific gravity | ||
Polypropylene | PVDF | |
|---|---|---|
Maximum Temperature: | 180º F (82º C) | 220º F (104º C) |
